Tail Lamp Cable Harness for 1987 Mercedes-Benz 300TD
No.
Part # / Description / Price
Price
5
Line
Mercedes-Benz
Mercedes-Benz Notes: FOR VEHICLES WITH TRAILER COUPLING ORDER WIRING HARNESS,SEE KG 31.
Description: Tail lamp cable harness.
8
Plug Housing Mercedes-Benz
Mercedes-Benz Description: 4-matic cable harness plug-connection. 8-pin rk4.0. Cockpit cable harness. 8-pin rk4.0. Rear speed sensor plug connection, bipolar. 8-pin rk4.0. Rpm sensor asr. 8-pin rk4.0.
MSRP $4.90
$4.35
MSRP $4.90
$4.35
8
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz Description: To 006 543 81 28. 8-pole. To 006 545 81 28,009 545 53 28. To 006 545 20 28.
10
Contact Pin Mercedes-Benz
Mercedes-Benz Description: 4.0 MM. 4.0 MM2 RK4Leitungsquerschnitt Min/Max: 4,0mm2Oberflächenschutz PINs: AgELA: -Model 1: RKModel 2: 4.0Release tool: W220 589 01 99 52. TO 009 545 53 28/56 28. 4.0 MM2 RK4Leitungsquerschnitt Min/Max: 4,0mm2Oberflächenschutz PINs: AgELA: -Model 1: R ...
MSRP $2.40
$2.10
MSRP $2.40
$2.10
11
Housing Upper Part Mercedes-Benz
Mercedes-Benz Description: To 009 545 78 28. To 009 545 80 28. Pin bushing housing 6-polig. To 006 545 08 28. To 006 545 78 28 (asr). 6-pole. To 006 545 80 28,123 545 06 28. (plug upper part).
MSRP $3.20
$2.85
MSRP $3.20
$2.85
15
MSRP $3.00
$2.70
17
MSRP $3.70
$3.33
18
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz Description: Automatic antenna. 4-pin rk2.5. Valve strip. Fourpole. 4-pin rk2.5. Tempmatik control box. 6-pole. 4-pin rk2.5. Inboard feeler blower. 4-pin rk2.5. Electrical antenna,6-pole. 4-pin rk2.5. Ventilation blower. 4-pin rk2.5. Pre-glow time relay. 4-pole. 4-pin rk2.5.
21
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Control unit. 10-pin. Lamp control device,10-pole. 10-pin. 10-polig. 10-pin.
24
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Interior rear lamp switch. Backrest adjustment interlock switch.
24
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Windshield washer/dome-lamp switch. 6-pin. Folding top actuation switch. 6-pin.
24
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Dome lighting. Dome lamp. Blinker light and speedometer. Time-lag relay.
25
Contact Socket Mercedes-Benz
Mercedes-Benz Description: 2.5 M. 0.35-2.5 MM2 RK2.5Leitungsquerschnitt Min/Max: 0,35-2,5mm2Oberflächenschutz PINs: AgELA: -Model 1: RKModel 2: 2.5Release tool: W220 589 01 99 30 / W220 589 01 99 53Crimp tool: W220 589 01 99 06. TO 201 540 02 81. 0.35-2.5 MM2 RK2.5Leitungsquerschni ...
MSRP $2.70
$2.40
MSRP $2.70
$2.40
36
Screw Mercedes-Benz
Mercedes-Benz Description: Tail lamp ground cable to wheel arch panel. Temperature switch cable to bell housing. Ground connection. Main cable harness to radiator baffle, right. Bracket mounting m4x10.
38
Spring Lock Washer Mercedes-Benz
Mercedes-Benz Description: Cables to cable connector. At front center stiffening. Blinker & tempomat switches to steering column jacket tube. Cable to resistor. Main cable harness to radiator baffle, right. Starting cable to cable connector.
MSRP $1.40
$1.20
MSRP $1.40
$1.20
44
Clamp Mercedes-Benz
Mercedes-Benz Description: Rear door contact branch-off to central pillar. 27.8 x 50.0 mm. Electric cable to side member. 27.8 x 50.0 mm. Window regulator cable harness to side member. 27.8 x 50.0 mm. Electric cable to wheel arch. 27.8 x 50.0 mm. Electric cable to tailgate. 27.8 x 50.0 mm. Plug-socket cable to frame. 27.8 x 50.0 mm. 22,75mm. 27.8 x 50.0 mm.
47
