Exhaust System Used on Eight-Cylinder Gasoline Vehicles for 2009 Mercedes-Benz CL63 AMG
No.
Part # / Description / Price
Price
10
Exhaust Pipe
Mercedes-Benz
Mercedes-Benz Notes: PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
Description: Front left.
20
Exhaust Pipe Mercedes-Benz
Mercedes-Benz Notes: PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
Description: Front right.
30
Screw Mercedes-Benz
Mercedes-Benz Description: Catalyst to exhaust manifold. M8x55. Power steering pump to bracket. Exhaust pipe mount. Catalytic converter to exhaust manifold. Front exhaust pipe to exhaust manifold. Front muffler to manifold. Exhaust line to exhaust manifold. Catalytic converter to turbocharger.
MSRP $5.00
$4.50
MSRP $5.00
$4.50
200
Shim Plate Mercedes-Benz
Mercedes-Benz Description: Bracket to transmission. Front exhaust pipe to transmission. To engine mount carrier. To engine mount rear. Left and right holder to transmission. Holder to oil pan. Exhaust system to transmission. Left bracket on right bracket.
MSRP $6.00
$5.40
MSRP $6.00
$5.40
210
Protective Metal Sheet Mercedes-Benz
Mercedes-Benz Description: Holder to oil pan. To engine mount carrier. Left and right holder to transmission. At engine mount carrier. To engine mount rear. Left bracket on right bracket.
MSRP $19.50
$17.25
MSRP $19.50
$17.25
220
Plate Mercedes-Benz
Mercedes-Benz Description: Left and right holder to center exhaust system. Front exhaust pipe to transmission. Bracket to front exhaust pipe. To engine mount rear. Exhaust gas line to holder. Left and right front exhaust system to holder.
MSRP $5.00
$4.50
MSRP $5.00
$4.50
230
Shim Plate Mercedes-Benz
Mercedes-Benz Description: To holder. Bracket to exhaust pipe. To engine mount rear. On bracket at left and right.
MSRP $6.50
$5.70
MSRP $6.50
$5.70
240
Hex Nut W Clamping Part Mercedes-Benz
Mercedes-Benz Description: M6
Diameter: 6mm
Strength / hardness class: 8
Thread code letter: M
Thread pitch: 1mm
Outside diameter: 14,2mm
Width across flats: 10mm. Catalytic converter to cylinder head, left and right. Left and right holder to center exhaust system. Front exhaust pipe to bracket. Bracket to engine mounting. Exhaust manifold on cylinder head. Exhaust gas line to holder. Left and right front exhaust system to holder.
Diameter: 6mm
Strength / hardness class: 8
Thread code letter: M
Thread pitch: 1mm
Outside diameter: 14,2mm
Width across flats: 10mm. Catalytic converter to cylinder head, left and right. Left and right holder to center exhaust system. Front exhaust pipe to bracket. Bracket to engine mounting. Exhaust manifold on cylinder head. Exhaust gas line to holder. Left and right front exhaust system to holder.
MSRP $2.70
$2.40
MSRP $2.70
$2.40
240
Hexagon Nut Mercedes-Benz
Mercedes-Benz Notes: THE OLD PART MUST NO LONGER BE INSTALLED
Description: M6
Diameter: 6mm
Strength / hardness class: 8
Thread code letter: M
Thread pitch: 1mm
Outside diameter: 14,2mm
Width across flats: 10mm. Catalytic converter to cylinder head, left and right. Front exhaust pipe to bracket. Exhaust manifold. Bracket to engine mounting. Rear left and right.
Diameter: 6mm
Strength / hardness class: 8
Thread code letter: M
Thread pitch: 1mm
Outside diameter: 14,2mm
Width across flats: 10mm. Catalytic converter to cylinder head, left and right. Front exhaust pipe to bracket. Exhaust manifold. Bracket to engine mounting. Rear left and right.
MSRP $1.50
$1.35
MSRP $1.50
$1.35
250
Clamp Mercedes-Benz
Mercedes-Benz Description: Catalyst to rear exhaust pipe. Flange connection of left and right rear exhaust line. Rear left exhaust pipe. Exhaust system front to rear muffler. Front exhaust pipe. Left exhaust pipe to right exhaust pipe.
MSRP $26.00
$23.25
MSRP $26.00
$23.25
255
Sealing Ring Mercedes-Benz
Mercedes-Benz Description: Front exhaust system to center exhaust system. Right exhaust system. Front exhaust pipe to rear exh. Pipe (slip fit). Front left and right. Rear left exhaust pipe. Exhaust pipe to rear exhaust pipe.
260
Damping Insert Mercedes-Benz
Mercedes-Benz Description: On rear subframe. To rear axle carrier. Central muffler suspension.
MSRP $12.50
$10.95
MSRP $12.50
$10.95
270
MSRP $16.50
$14.55
280
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description: Cross member to left front panel pillar.
MSRP $2.70
$2.40
MSRP $2.70
$2.40
295
Elastomer Suspension Mercedes-Benz
Mercedes-Benz Description: Left and right. Central exhaust pipe. Main muffler rear suspension. Central suspension.
310
Bar Mercedes-Benz
Mercedes-Benz Description: Connection of exhaust pipes TOGETHER. Connection of exhaust pipes with each other.
MSRP $28.50
$25.50
MSRP $28.50
$25.50
315
MSRP $4.90
$4.41
330
Suspension Ring Mercedes-Benz
Mercedes-Benz Description: Rear to body. Posterior muffler. Rear on bodyshell. Central muffler suspension.
MSRP $10.00
$9.00
MSRP $10.00
$9.00
340
MSRP $21.00
$18.75
350
Lambda Sensor Mercedes-Benz
Mercedes-Benz Description: Left control probe in front of catalyst. Right control probe in front of catalyst. Control sensor upstream twc conv. Left and right. Left, upstream of catalytic converter. Right primary catalytic converter.
MSRP $382.00
$308.76
MSRP $382.00
$308.76
350
Lambda Sensor Mercedes-Benz
Mercedes-Benz Description: Catalytic converter, left. Diagnostic sensor downstream of catalytic converter. Diagnosis probe behind catalyst.
MSRP $336.00
$271.35
MSRP $336.00
$271.35
370
Holder Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Front exhaust pipe to transmission, right.
380
Hexalobular Screw Mercedes-Benz
Mercedes-Benz Description: Door check to door. M10X50
Diameter: 10mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1mm. Engine-trans. Connection w. Bracket for exhaust manifold. Bracket to transmission.
Diameter: 10mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1mm. Engine-trans. Connection w. Bracket for exhaust manifold. Bracket to transmission.
MSRP $47.50
$41.33
MSRP $47.50
$41.33
400
Holder Mercedes-Benz
Mercedes-Benz Description: 02 sensor to transmission. Sensor line at transmission bell housing. O2 sensor. Sensor cable. Oxygen sensor;contact to lower transmission bell.
MSRP $149.00
$129.05
MSRP $149.00
$129.05
