Radiator, Mounting, and Covering for 2009 Mercedes-Benz E320
No.
Part # / Description / Price
Price
10
Cooler
Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Cooling water. Water cooler.
MSRP $730.00
$591.30
MSRP $730.00
$591.30
11
Catch Spring Mercedes-Benz
Mercedes-Benz Description: Scb36 46.4mm. Cooling water hose to radiator. Housing. At shell. Preheater. To upper coolant hose. To left radiator. To left cooler. Pipe elbow.
MSRP $4.00
$3.60
MSRP $4.00
$3.60
12
Sleeve Mercedes-Benz
Mercedes-Benz Description: Water cooler. Transmission oil line to radiator. Transmission oil line to oil cooler. At radiator, top.
MSRP $12.00
$10.65
MSRP $12.00
$10.65
14
MSRP $12.50
$11.25
30
MSRP $905.00
$688.64
35
MSRP $172.00
$139.05
40
Clip-Type Nut Mercedes-Benz
Mercedes-Benz Description: Fan shroud to radiator. Blower to radiator. Fan shroud to cooler top. Cover to radiator. Fan fastening.
MSRP $4.00
$3.53
MSRP $4.00
$3.53
50
MSRP $1.50
$1.35
60
Clamp Mercedes-Benz
Mercedes-Benz Description: Tube to rear pillar. Hose to right rear pillar. Main cable harness to fire wall.
65
Clamp Mercedes-Benz
Mercedes-Benz Description: For hose to body. 20 mm. De-aeration line. 20 mm. Cable harness mounting. 20 mm. Wiring harness. 20 mm. Bracket mounting. 20 mm. Hose to engine. 20 mm. Mounting, vent lines to corrugated hose, right. 20 mm. Adapter cable to fan shroud. 20 mm. Filler neck. 20 mm. Breather line to engine. 20 mm.
MSRP $2.00
$1.80
MSRP $2.00
$1.80
75
Sealing Ring Mercedes-Benz
Mercedes-Benz Description: MOUNTING PLATE TO DRIER. 7.5X2.0 Strength / hardness class: EPDM Inside diameter: 7,5mm Outside diameter: 11,5mm Material thickness: 2mm. Heater. 7.5X2.0 Strength / hardness class: EPDM Inside diameter: 7,5mm Outside diameter: 11,5mm Material thickness: 2m ...
$3.90
$3.90
77
MSRP $12.00
$10.65
80
Refrigerant Drier For AC Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Drying insert. At condenser. Air conditioner.
MSRP $340.00
$274.05
MSRP $340.00
$274.05
100
Metal Mounting Sheet Mercedes-Benz
Mercedes-Benz Description: At dehydrator. Pressure lines to drier. Drier to condenser.
MSRP $8.00
$7.05
MSRP $8.00
$7.05
105
Hexalobular Screw Mercedes-Benz
Mercedes-Benz Description: At dehydrator. M8X25
Diameter: 8mm
Strength / hardness class: 8.8
Thread code letter: M
Thread pitch: 1mm.
Diameter: 8mm
Strength / hardness class: 8.8
Thread code letter: M
Thread pitch: 1mm.
MSRP $2.20
$1.95
MSRP $2.20
$1.95
170
MSRP $46.00
$39.88
250
Elastomer Bearing Mercedes-Benz
Mercedes-Benz Description: Radiator bottom. Lower cooler. Soundproofing. Left and right bottom.
260
Bearing Mercedes-Benz
Mercedes-Benz Description: Upper cooler. Radiator suspension,top. Left upper. Cooler to reinforcement. Bearing, radiator mount, upper. 2.0L - diesel om654 2023-25 auxiliary.
MSRP $13.50
$11.85
MSRP $13.50
$11.85
260
MSRP $7.50
$6.60
270
MSRP $7.75
$6.90
270
MSRP $7.50
$6.60
800
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Fan motor m4/7. 4-pin slk2.8, lsk8. Cooler fan 4-pin m4/7. 4-pin slk2.8, lsk8. Fan motor n76. 4-pin slk2.8, lsk8. Electric suction-type fan control module engine / a/c n76. 4-pin slk2.8, lsk8. Fan motor n65/1. 4-pin slk2.8, lsk8. Ac blower control unit box n65/2. 4-pin slk2.8, lsk8. Auxiliary fan. 4-pin slk2.8, lsk8. M4/3. 4-pin slk2.8, lsk8. Cooler blower m4/7_a. 4-pin slk2.8, lsk8.
MSRP $9.25
$8.25
MSRP $9.25
$8.25
810
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
MSRP $7.50
$6.69
MSRP $7.50
$6.69
810
Contact Socket Mercedes-Benz
Mercedes-Benz Description: 8.0-12 MM2 LSK8
Leitungsquerschnitt Min/Max: 8,0-12,0mm2
Oberflächenschutz PINs: Ag
ELA: +
Model 1: LSK
Model 2: 8
Release tool: W220 589 01 99 56.
Leitungsquerschnitt Min/Max: 8,0-12,0mm2
Oberflächenschutz PINs: Ag
ELA: +
Model 1: LSK
Model 2: 8
Release tool: W220 589 01 99 56.
MSRP $6.25
$5.55
MSRP $6.25
$5.55
1 This price excludes a refundable manufacturer's core charge. Add the part to your cart to see the core charge.
