Accessories Used for Wireless Plants for 1998 Mercedes-Benz E430
No.
Part # / Description / Price
Price
10
50
Interfer Suppr Filter
Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Radiocommunication. Emergency vehicles. At apparatus plate.
55
Transmitter Mercedes-Benz
Mercedes-Benz Description: Radio remote control for taxi alarm call. Radio remote control activation. Sender funkfernausloeser. Taxi emergency alarm.
120
Contact Socket Mercedes-Benz
Mercedes-Benz Description: 0.75mm2. 0.75 MM2
Leitungsquerschnitt Min/Max: 0,5-0,75mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: MQS.
Leitungsquerschnitt Min/Max: 0,5-0,75mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: MQS.
MSRP $5.25
$4.65
MSRP $5.25
$4.65
120
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
MSRP $7.00
$6.30
MSRP $7.00
$6.30
130
Contact Socket Mercedes-Benz
Mercedes-Benz Description: 4 MM. 0.35-2.5 MM2 RK2.5Leitungsquerschnitt Min/Max: 0,35-2,5mm2Oberflächenschutz PINs: AgELA: -Model 1: RKModel 2: 2.5Release tool: W220 589 01 99 30 / W220 589 01 99 53Crimp tool: W220 589 01 99 06. 2,5 (AX). 0.35-2.5 MM2 RK2.5Leitungsquerschnitt Min/Ma ...
MSRP $2.90
$2.55
MSRP $2.90
$2.55
165
Contact Spring Mercedes-Benz
Mercedes-Benz Description: Left exit lights. 0.5 mm2 jpt. To 220 545 17 28. 0.5 mm2 jpt. 0,5-1,0mm2. 0.5 mm2 jpt. Radio 0.5 -1.0 mm2. 0.5 mm2 jpt.
MSRP $3.50
$3.15
MSRP $3.50
$3.15
210
Male Spade Connector Mercedes-Benz
Mercedes-Benz Description: 0.5-1 MM2. 1.0 MM2
Leitungsquerschnitt Min/Max: 0,5-1,0mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: MCP
Model 2: 2.8.
Leitungsquerschnitt Min/Max: 0,5-1,0mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: MCP
Model 2: 2.8.
220
Plug Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Radio selector switch. 6-pin e95. Seat heater switch. 6-pin e95.
230
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: HEATER BOOSTER SWITCH 0.5 - 1.0mm2. 0.75 MM2 E95 SN
Leitungsquerschnitt Min/Max: 0,75mm2
Oberflächenschutz PINs: Sn
Model 1: E95.
Leitungsquerschnitt Min/Max: 0,75mm2
Oberflächenschutz PINs: Sn
Model 1: E95.
MSRP $5.50
$4.80
MSRP $5.50
$4.80
230
Contact Spring Mercedes-Benz
Mercedes-Benz Description: 0,35MM. 0.5-1.0 MM2 E95Leitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: SnELA: -Model 1: E95Release tool: W220 589 01 99 55. 0,5-1,0 MM. 0.5-1.0 MM2 E95Leitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: SnELA: -Model 1: E95Relea ...
MSRP $5.00
$4.49
MSRP $5.00
$4.49
250
Crimp Tml Pin Contact Mercedes-Benz
Mercedes-Benz Description: X1/16. 0.5-0.75 MM2 MQSLeitungsquerschnitt Min/Max: 0,5-0,75mm2Oberflächenschutz PINs: SnELA: -Model 1: MQSRelease tool: W220 589 01 99 60Crimp tool: W220 589 01 99 85. Malfunction indicator lamp aut. Breakdown/information button conn. X 39/48. 0.5-0.75 M ...
MSRP $2.80
$2.48
MSRP $2.80
$2.48
No.
Part # / Description / Price
Price
14
Switch Mercedes-Benz
Mercedes-Benz Description: Radiophone. Hands-free system. Radio - government vehicle. Top covering.
17
Electric Coupling Mercedes-Benz
Mercedes-Benz Description: Loudspeaker connection cod.b. 8-POLE. 8-PIN JPTModel 1: JPT / MDK3Model 2: 3Slots: 8Release tool: W000 589 13 99 30. RADIO "B". 8-PIN JPTModel 1: JPT / MDK3Model 2: 3Slots: 8Release tool: W000 589 13 99 30. Inboard cable harness plug-connection. 8-pin jptm ...
20
Electric Line Mercedes-Benz
Mercedes-Benz Description: Electrical connection cables 2 m. Electrical connection cables 2m.
