Cable Harness for Radio, Loudspeaker and CD-Player for 1998 Mercedes-Benz E430
No.
Part # / Description / Price
Price
5
5
17
Spring Retaining Pin
Mercedes-Benz
Mercedes-Benz Description: 0.35.1.0 mm2. 1.5-2.5 mm2,1 polig. Unipolar. 1.5-2.5 mm2, 1polig. 1.5-2.5mm2.
MSRP $4.00
$3.60
MSRP $4.00
$3.60
20
Electrical Wiring Harness Mercedes-Benz
Mercedes-Benz Description: Repair solution contacting 0.75mm2. 0.75 mm2 e95. Fuse box. 0.75 mm2 e95.
MSRP $6.50
$5.70
MSRP $6.50
$5.70
23
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Radio 16-polig. 2x8-pin jpt. Radio plug-connection. 2x8-pin jpt. 16-pole. 2x8-pin jpt.
26
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Operating unit a2. 10-pin jpt. Radio 10-polig. 10-pin jpt. Radio set,10-pole. 10-pin jpt.
29
Contact Spring Mercedes-Benz
Mercedes-Benz Description: Left exit lights. 0.5 mm2 jpt. To 220 545 17 28. 0.5 mm2 jpt. 0,5-1,0mm2. 0.5 mm2 jpt. Radio 0.5 -1.0 mm2. 0.5 mm2 jpt.
MSRP $3.50
$3.15
MSRP $3.50
$3.15
29
Spring Retaining Pin Mercedes-Benz
Mercedes-Benz Description: 1.5-2.5mm2. 1.5-2.5 MM2 JPT2.8
Leitungsquerschnitt Min/Max: 1,25-2,5mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: JPT
Model 2: 2.8
Release tool: W000 589 13 99 30
Crimp tool: W220 589 01 99 05.
Leitungsquerschnitt Min/Max: 1,25-2,5mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: JPT
Model 2: 2.8
Release tool: W000 589 13 99 30
Crimp tool: W220 589 01 99 05.
MSRP $3.90
$3.45
MSRP $3.90
$3.45
32
Contact Spring Mercedes-Benz
Mercedes-Benz Description: Tin-plated. 1.5-2.5 MM2 MCP6.3
Leitungsquerschnitt Min/Max: 1,5-2,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: MCP
Model 2: 6.3. 1.5-2.5 MM. 1.5-2.5 MM2 MCP6.3
Leitungsquerschnitt Min/Max: 1,5-2,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: MCP
Model 2: 6.3. FUSE BOX 1.5-2.5mm2. 1.5-2.5 MM2 MCP6.3
Leitungsquerschnitt Min/Max: 1,5-2,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: MCP
Model 2: 6.3.
Leitungsquerschnitt Min/Max: 1,5-2,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: MCP
Model 2: 6.3. 1.5-2.5 MM. 1.5-2.5 MM2 MCP6.3
Leitungsquerschnitt Min/Max: 1,5-2,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: MCP
Model 2: 6.3. FUSE BOX 1.5-2.5mm2. 1.5-2.5 MM2 MCP6.3
Leitungsquerschnitt Min/Max: 1,5-2,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: MCP
Model 2: 6.3.
MSRP $1.50
$1.35
MSRP $1.50
$1.35
32
Plug Mercedes-Benz
Mercedes-Benz Description: Partition point pri. Veh. Warn. Sig. X41/4. 2-pin rk2.5. Door separation point. 2-pin rk2.5.
35
Contact Pin Mercedes-Benz
Mercedes-Benz Description: Partition point pri. Veh. Warn. Sig. X41/4. 1.1-2.5 MM2 RK2.5Leitungsquerschnitt Min/Max: 1,5-2,5mm2Oberflächenschutz PINs: SnELA: -Model 1: DIAModel 2: 2.5. DOOR SEPARATION POINT 1,0-2,5 MM2. 1.1-2.5 MM2 RK2.5Leitungsquerschnitt Min/Max: 1,5-2,5mm2Oberfl ...
MSRP $1.70
$1.50
MSRP $1.70
$1.50
38
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Roof mounted operating unit. 2 pin mcp2.8. Right rear speaker connector x1/1. 2 pin mcp2.8. Battery. 2 pin mcp2.8. Loudspeaker 2 polig. 2 pin mcp2.8. Loudspeaker, driver door, front left and right. 2 pin mcp2.8. Rear-mounted loudspeaker. 2 pin mcp2.8. Plug connection. 2 pin mcp2.8. Front speakers without radio h4/1 / h4/2. 2 pin mcp2.8.
41
Contact Spring Mercedes-Benz
Mercedes-Benz Description: 0,5-1,0mm2. 1.5-2.5 MM2
Leitungsquerschnitt Min/Max: 1,5-2,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: MCP
Model 2: 2.8. 1.5-2.5mm2. 1.5-2.5 MM2
Leitungsquerschnitt Min/Max: 1,5-2,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: MCP
Model 2: 2.8.
Leitungsquerschnitt Min/Max: 1,5-2,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: MCP
Model 2: 2.8. 1.5-2.5mm2. 1.5-2.5 MM2
Leitungsquerschnitt Min/Max: 1,5-2,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: MCP
Model 2: 2.8.
No.
Part # / Description / Price
Price
30
Plug Housing Mercedes-Benz
Mercedes-Benz Description: Instrument cluster abs/ets, "m". 2-pin mqs. Instrument cluster cod-m. 2-pin mqs.
35
Contact Socket Mercedes-Benz
Mercedes-Benz Description: 0.75mm2. 0.75 MM2
Leitungsquerschnitt Min/Max: 0,5-0,75mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: MQS.
Leitungsquerschnitt Min/Max: 0,5-0,75mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: MQS.
MSRP $5.25
$4.65
MSRP $5.25
$4.65
35
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
MSRP $7.00
$6.30
MSRP $7.00
$6.30
40
Plug Housing Mercedes-Benz
Mercedes-Benz Description: Airmatic emergency filling connecting point x222. 6-pin mqs
model 1: mqs
slots: 6. Air suspension sep. Point x11/35. 6-pin mqs
model 1: mqs
slots: 6. Front door handle x8/34, x8/35. 6-pin mqs
model 1: mqs
slots: 6. Door separation point. 6-pin mqs
model 1: mqs
slots: 6. From light range regulator to front axle 13-polig. 6-pin mqs
model 1: mqs
slots: 6.
model 1: mqs
slots: 6. Air suspension sep. Point x11/35. 6-pin mqs
model 1: mqs
slots: 6. Front door handle x8/34, x8/35. 6-pin mqs
model 1: mqs
slots: 6. Door separation point. 6-pin mqs
model 1: mqs
slots: 6. From light range regulator to front axle 13-polig. 6-pin mqs
model 1: mqs
slots: 6.
MSRP $38.50
$33.35
MSRP $38.50
$33.35
55
Male Spade Connector Mercedes-Benz
Mercedes-Benz Description: 1.5-2.5 MM2 MCP2.8
Leitungsquerschnitt Min/Max: 1,5-2,5mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: MCP
Model 2: 2.8.
Leitungsquerschnitt Min/Max: 1,5-2,5mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: MCP
Model 2: 2.8.
MSRP $2.50
$2.25
MSRP $2.50
$2.25
60
Electrical Wiring Harness Mercedes-Benz
Mercedes-Benz Description: FUSE BOX 1.5-2.5mm2. 2.5 MM2
Leitungsquerschnitt Min/Max: 2,5mm2
Oberflächenschutz PINs: -
Model 1: GSK.
Leitungsquerschnitt Min/Max: 2,5mm2
Oberflächenschutz PINs: -
Model 1: GSK.
MSRP $5.50
$4.95
MSRP $5.50
$4.95
60
Cable Harness Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: FUSE BOX. 4.0 MM2 GSK1
Leitungsquerschnitt Min/Max: 4,0mm2
Oberflächenschutz PINs: -
Model 1: GSK
Model 2: 1.
Leitungsquerschnitt Min/Max: 4,0mm2
Oberflächenschutz PINs: -
Model 1: GSK
Model 2: 1.
60
Spring Retaining Pin Mercedes-Benz
Mercedes-Benz Description: FUSE BOX 2.5-4.0 MM2, 1POLIG. 1-PIN 2.5-4.0 MM2 GSK
Leitungsquerschnitt Min/Max: 2,5-4,0mm2
Oberflächenschutz PINs: blank
ELA: -
Model 1: GSK.
Leitungsquerschnitt Min/Max: 2,5-4,0mm2
Oberflächenschutz PINs: blank
ELA: -
Model 1: GSK.
MSRP $3.70
$3.30
MSRP $3.70
$3.30
320
Male Spade Connector Mercedes-Benz
Mercedes-Benz Description: 0.5-1 MM2. 1.0 MM2
Leitungsquerschnitt Min/Max: 0,5-1,0mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: MCP
Model 2: 2.8.
Leitungsquerschnitt Min/Max: 0,5-1,0mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: MCP
Model 2: 2.8.
350
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
SIMPLE PART-PLEASE HAVE SHOP MADE
SIMPLE PART-PLEASE HAVE SHOP MADE
Description: Wake-up.
No.
Part # / Description / Price
Price
5
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: FROM IDENT.NO.; INTEGRATED IN REAR LIGHT CABLE HARNESS;REFER TO TU 54/545
Description: Radio set-sound system.
5
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: FROM IDENT.NO.; INTEGRATED IN REAR LIGHT CABLE HARNESS;REFER TO TU 54/545
Description: Radio set-sound system.
No.
Part # / Description / Price
Price
53
Switch Mercedes-Benz
Mercedes-Benz Description: Distress call. Roadside/info. E-call. Center armrest. Breakdown/info pushbutton.
MSRP $145.00
$126.15
MSRP $145.00
$126.15
